Shaft Power from Torque and Speed
Rotating machinery is rated by power, which is the product of torque and angular speed. This is the bridge between a motor’s nameplate and the torque a shaft must carry.
Rotational power is P = T·ω. where T is the torque and ω the angular velocity in radians per second.
Inputs
T := 150 N·m=150 Nm
omega := 157 rad/s=157 Hz
Multiply torque by angular velocity to get power.
P := T·omega=23550 W
Results
The result is the transmitted power. For a fixed power, torque and speed trade off inversely — which is exactly what a gearbox exploits.
Assumptions & limitations
- Steady-state rotation, constant torque.
- No transmission losses.
- Angular speed expressed in rad/s.
