Shear Reinforcement Capacity
Stirrups carry the shear the concrete alone cannot; their capacity follows the truss analogy.
The stirrup shear capacity is V_s = A_v·f_y·d/s. where A_v is the stirrup area, f_y its yield strength, d the effective depth and s the spacing.
Inputs
A_v := 157 mm^2=1.57e-04 m^2
f_y := 500 MPa=500 MPa
d := 450 mm=450 mm
s := 200 mm=200 mm
Apply the truss-analogy stirrup capacity.
V_s := A_v·f_y·d/s=176625 N
Results
Closer stirrup spacing increases capacity. The total shear capacity adds the concrete contribution to this steel term.
Assumptions & limitations
- Vertical stirrups, 45° truss model.
- Stirrups yield.
- Adds to the concrete shear term.
